YG60 60°Accurate Gloss Meter

60° Professional Precision Gloss Meter

The 3NH YG60 glossiness meter is a glossiness measuring instrument designed and manufactured in accordance with the international standard ISO2813, equipped with high-end quality management software, and meets the requirements of JJG696 first level working glossiness meter


Key Highlights

  • Suitable for surface measurement with Medium Gloss

  • Meet the requirements of JJG696 working glossiness meter

  • Large capacity storage space, 35000 measurement data;

  • Ergonomic Design

  • Multiple working modes, multiple function settings

This YG60 Instrument are Certified with
certify
1 Years Warranty (Additional support period of 3 years)

YG60 60°Accurate Gloss Meter is independently developed by Shenzhen 3nh Technology Co., Ltd with independent intellectual property, manufactured according to international standard ISO2813 and China standard GB/T 9754. With auto-calibration and high-end QC software, it can meet the first  grade requirements of JJG696.

YG series gloss meter also features with USB/RS-232 interface and Blutooth 2.1 dual mode.


Features:


1. Elegant Design combined with aesthetics and ergonomics;
2. With auto-calibration function;
3. Meet the first grade requirements of JJG696;
4. Large storage to save over 35000 data;
5. Auto Power-off within optional 30-120 seconds;
6. Comply to ISO2813, ASTM523, GB/T9754;
7. With PC software for quality report, more extend functions;
8. With multi working modes and multi-functions for most customers’ requirements.


Application:


Widely used in the filed of paints, coating, plastics, ink, rubber, printing, paper, glass, handware, ceramic, marble etc.
yg60_applications

Specifications:


ModelYG60 60°Accurate Gloss Meter
Measuring Angle60°
Measuring Area60°: 0-1000GU
Division Value0.1GU
Measuring ModesBasic mode; Statistic mode; Continuous mode; QC mode
Measuring Time0.5S
Repeatability0~100GU : ±0.2GU; 100~1000GU : ±0.2%GU
AccurateConform with JJG696 first grade requirements of gloss meter
Auto Power-off TimeWithin 30s-120s
Long-time CalibrationAutomatically check and made the calibration
LanguageChinese & English
Storage35000(Basic mode &Statistic mode : 1500;
           Continuous mode : 10000;
           QC mode: 10000)
Display2.3 inch white and black screen
Size160*52*84mm
WeightAbout 300g
Power Supply1pc dry-cell battery(can measure 10000 times) or use USB Charge
InterfaceUSB & Bluetooth 2.1 version
PC SoftwareGQC6 QC software can printing testing report and with more extended functions
Operation Temperature Range0-40℃(32-104° F)
Storage Temperature Range-20-50℃(-4-122° F)
Humidity Range< 85% RH, without condensation
Standard AccessoriesUSB cable, user manual, calibration plate, QC software
Optional AccessoriesMiniature printer
Notification: the technical parameter is only for reference



Our Valued Clients

FAQs About YG60  Gloss meter

Gloss is a broad term to describe the reflectivity of a surface. Whereas high gloss is a specific term that has the highest reflectance (usually more than 70 GU). High gloss finishes are shiny, mirror-like, and exhibit more surface blemishes than lower gloss finishes.


Smooth and uniform surfaces with a large amount of reflected light directly result in high gloss. Some of the factors are the smoothness of the surface, the type of paint that is being used, the thickness of the coating, and curing. The lesser the surface irregularities, the greater the gloss.


An 80 gloss surface will reflect less light as compared to a 100 gloss surface. Both are said to be high gloss, although 100 GU (or higher) reflects almost as much as a mirror. The distinction can be slight in graphic terms, but major in specific uses.


A paint gloss meter is used to measure the level of paint gloss, whereby it reflects light at some angles, such as 20°, 60°, or 85° angles, and measures the intensity of that light. To measure surface sheen, the level of gloss is compared to standards that are calibrated and reported in units of gloss (GU).


 The five common gloss levels are:

1. Flat/Matte (0–10 GU)

2. Eggshell (10–25 GU)

3. Satin (26–40 GU)

4. Semi-gloss (41–70 GU)

High Gloss (71–100+ GU)
These levels vary slightly depending on industry and standards used.
